Chapter 4: Development Board Setup
Factory Default Switch Settings
Table 4–4. Jumper Settings (Part 2 of 2)
4–7
Board
Reference
Board
Label
Function
Default
Shunt Position
This jumper has the following options:
■
Installing the shunt on pins 1 and 2 sets VCC and VCCL to 0.9 V.
J21
VCC_VCCL_SEL
■
■
Installing the shunt on pins 2 and 3 sets VCC and VCCL to 1.1 V.
Removing the shunt sets VCC and VCCL to 0.6 V.
Installed on
pins 1 and 2
Always keep a shunt installed on pins 1 and 2 only. The current version
of the Stratix IV E device requires 0.9 V.
To use the RLDRAM II impedance drive jumpers, set the mode
register. When the mode register is not set, the RLDRAM II output
impedance is 50 Ω . The RLDRAM II impedance drive jumpers have the
following options:
■
Installing the shunt on pins 1 and 2 sets the RLDRAM II output
J28
RLD_ZQ_IMPED
■
impedance to the maximum value possible.
Installing the shunt on pins 3 and 4 sets the RLDRAM II output
Not installed
impedance to 50 Ω .
■
Installing the shunt on pins 5 and 6 sets the RLDRAM II output
impedance to 60 Ω .
Installing more than one shunt might cause damage to the device.
f For more information about the FPGA board settings, refer to the Stratix IV E FPGA
Development Board Reference Manual .
June 2011
Altera Corporation
Stratix IV E FPGA Development Kit User Guide
